A Welded Plate Compact Heat Exchanger (WPCHE) is a highly efficient and compact heat transfer device that uses a series of parallel plates welded together to form a single unit. The plates are designed with corrugations that increase the surface area for heat transfer and promote turbulence in the fluid flow, enhancing the efficiency of heat exchange. This design makes WPCHEs particularly suitable for applications requiring high heat transfer rates in a small footprint.

A welded plate heat exchanger (WPHE) is a type of heat exchanger that uses a series of corrugated metal plates welded together by laser or argon arc welding. The plates are connected with molding strips, and there are no gaskets between the plates, making it suitable for high-temperature and high-pressure applications. WPHEs are divided into several types, including non-detachable fully welded, 2-sided detachable fully welded, 4-sided detachable fully welded (HFM bloc), and wide channel fully welded plate heat exchangers.

Unlike gasketed plate heat exchangers, WPHEs do not use gaskets or seals between the plates, making them suitable for applications where leakage is a concern.

The Welded Plate Heat Exchanger is a versatile and efficient solution for industrial heat transfer needs. Its compact design, high performance, and reliability make it a preferred choice for applications requiring high temperature and pressure resistance.

Materials: The fresh water generator plates supplied by UNO PHE are made of Japanese titanium or Chinese titanium Grade 1 material.

Grade 1 titanium alloy is a high-purity titanium alloy, also known as CP (commercial pure) titanium alloy, its chemical composition of titanium content of more than 99.5%, with excellent corrosion resistance, high strength and low density characteristics.

Thickness: The thickness of the plate is 0.5mm. This thickness of the plate not only ensures the strength, but also helps to improve the heat exchange efficiency.

UNO PHE offers new equivalent gaskets for fresh water generators. All Fresh Water Generator gaskets are made in the best rubber material quality which will ensure a correct fit.

Working principle and structure
Structure principle: Plate heat exchanger is composed of a series of pressed corrugated metal plates, which are separated by sealing gaskets and pressed by the frame and compression bolts to form a compact structure.

Working principle: Hot fluid and cold fluid flow between the plates, through the plate for heat exchange. A partition in the middle of the plate separates the hot and cold fluids, ensuring that they exchange heat as they flow.

The semi-welded plate heat exchanger is a highly efficient heat transfer device that uses plates to exchange heat between two fluids. This type of heat exchanger features welded channels on one side, while the other side remains gasketed. This design allows for efficient heat transfer while also providing superior reliability and durability.

In the Semi-welded heat exchanger the refrigerant flows in laser-welded, sealed plate channels, and in the opposite channel the liquid brine flows in gasketed channels.

Plate heat exchanger is made of alloy plate or stainless steel, The heat transfer plate has a perfect embossing, Choose different materials to withstand corrosion from different media.Because of the variety of embossing can produce variable flow gap.We can provide the perfect heat exchanger plates which can replace the original plate perfectly.In order to ensure traceability of heat exchanger plates, we strictly implement the requirements of ISO9000, strictly control every link of production and conduct strict delivery inspection.
NEW ROC UNO supplies OEM heat exchanger plates replacements.

Because of the perfect materials, strict production process and delivery inspection standards, we have perfect products.We strictly enforce the requirements of ISO9000, so that each Gasket has can be traced back.

After years of efforts in the OEM and aftermarket we have now accumulated more than 400 types of PHE Gasket mold, and meet gasket NBR, HNBR，NBR-HT,EPDM,HEPDM,VITON manufacturing and they meet FDA standards.

NEW ROC UNO supplies OEM heat exchanger gaskets replacements. We have now accumulated more than 100 types of OEM PHE Gasket mold.

UNO Brazed Plate Heat Exchangers provide maximum heat dissipation from a compact, lightweight heat exchanger, so they are ideal for residential and light commercial hydronic systems. Unlike conventional shell and tube heat exchangers, our units can be used even in applications where space is at a premium.

We can provide you with the heat exchanger machine suitable for you according to the heat exchange parameters and media you need,our gasketed Plate Heat Exchangers are suitable for all type of industries with multiple applications.Our plate heat exchanger can be used in the field of air-conditioner, stores, petroleum chemicals, boats and ships, food and drinks, iron and steel , recycling of the heat.Our plate heat exchangers are designed to flexibly meet a wide range of needs,and we also have perfect manufacturing and after-sales service to ensure a good customer experience.
